Home > Electronics > MXO-Racing FLYSKY AFHDS 1A V2 Micro ANTENNA-FREE Receiver #RXC42-A1-NT

1/1

MXO-Racing FLYSKY AFHDS 1A V2 Micro ANTENNA-FREE Receiver #RXC42-A1-NT

Name: MXO-Racing FLYSKY AFHDS 1A V2 Micro ANTENNA-FREE Receiver #RXC42-A1-NT
Brand: GT55racing
SKU: RXC42-A1-NT
Price: 31.9 USD
Availability: InStock

SKU: RXC42-A1-NT

0.0 (0)

15 Sold

$31.90

Features

1)Modulation:Compatible FlySky AFHDS
2)Small size: 21.5*14.6*6.5mm(not including antenna)
3)Super light: 2.4g(including antenna)
4)Working voltage:3.7~8.4V
5)High performance CPU enhance exactness control feeling

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (1)

1/1

Description

MXO-RACING RXC42-A1-NT(FLYSKY-AFHDS-1A) V2 Super Micro SurfaceRX/ABS shell/4CH/MINIZ/ATM/DRZ/GL

This RC receiver unit is FlySky AFHDS compatible. It offers full 4-channel support in ultra-light weight and micro size. It is designed for micro racing cars.

Features

1)Modulation:Compatible FlySky AFHDS
2)Small size: 21.5*14.6*6.5mm(not including antenna)
3)Super light: 2.4g(including antenna)
4)Working voltage:3.7~8.4V
5)High performance CPU enhance exactness control feeling
6)4 channel support
7)Added failsafe function
8)Ideal for any micro RC racing chassis
9)Comes with 3P 1.5mm plug

Compatible Transmitters

FS GT2
FS GT2B
FS GT3
FS GT3B
FS GT3C
FS CT6A
FS CT6B
FS T6
FS TH9X
FS I4
FS I4X
FS I6
FS I6X
FS I10
FS T8SG
FST12
FST12PRO
FST16
FS T16PRO

Connection Diagram

Bind and Failsafe

Power on your transmitter and receiver. Adjust transmitter each channel to the exact position you want to have in failsafe mode. Transmitter set to pair mode. Receiver led should be on. Long press the pair button. After around 2 seconds the LED will turn to fast flashing first then turn to on status again. Now the pairing is done and the failsafe data is saved. Power off the transmitter and receiver then power on again then the receiver will work.
