MXO-RACING SANWA FH5 Built-in Transponder TOWER ANTENNA RECEIVER RXC52-F5&TP

Thank you for choosing MXO-RACING brand products!
Please read this document carefully before use.

Product Overview

The RXC52-FH5&TP is a miniature antennaless high-speed surface receiver, integrated with a Transponder. It is compatible with the SANWA FH5 protocol and is suitable for 1:24/1:28 or MINIZ models.

Compatible Transmitters:

• Sanwa M17

• Sanwa MT-5

Features

• Size: 19.6 × 12.0 × 7.0 mm

• Weight: 1.35g

• Working Voltage: 3.3V ~ 8.5V

• Compatible Protocol: SANWA FH4

• Built-in LNA (Low Noise Amplifier)

• Built-in Transponder with editable personal ID number

• Personal ID Range: 1 ~ 16,777,215

• Parallel High-Speed Output

• Supports 2.6ms High-Speed Output



Interface and LED Indicators (Figure 1)

Blue LED (Receiver Status)

• Fast Flashing: Receiver is connected

• Slow Flashing: Receiver is waiting for a signal from the transmitter

• Solid: Receiver has received the transmitter's signal and is working normally

Red LED (Transponder Status)

• Off: Transponder is off or not present

• Solid: Transponder is active and working

LNA (Low Noise Amplifier) Function

The LNA is an electronic component designed to improve the operating distance and response speed of the receiver. When the transmitting power of certain transmitters is too low, the receiver with LNA significantly improves the response feel and operating performance, making it ideal for drifting and racing models.

Binding Operation (BIND)

1. Press and hold the BIND switch

2. Power on the receiver

3. When the blue LED flashes rapidly, release the BIND switch—this indicates that the receiver is in BIND mode

4. Complete the BIND operation following the transmitter’s BIND procedure

Editing Transponder's Personal ID Number

The RXC52-FH5&TP has a built-in Transponder that allows users to edit their personal ID number. To do so, you will need the MX USB PG-ISP to connect the receiver to the GUI.

Personal ID Editing Tool:
Visual editing tools are available (see Figure 2).

Before editing the personal ID, connect the receiver to the GUI via the MX USB PG-ISP as shown in Figure 3.

GUI Software Download

https://store.mxo-rc.com/download-gui
